Crawler Impact Crushing Station
| ①Impact Crusher | ②Power Unit | ③Main belt conveyor | |
|
Feeding port: 860mmx1520mm Maximum processing capacity: 220t/h Motor power: 220kw |
Rubber side panels on both sides | ||
| ④Iron remover | ⑤ Tracks | ⑥ladder&aisle | ⑦Receiving hopper /feeding machine |
| Suspended iron remover(Height adjustable) |
Heavy-duty structure, suitable for various environments |
Easy to maintain equipment | Hopper capacity:9m3 |
| Model | Scope of application(Primary crushing) |
Processing capacity (Bulk density1.6t/m³) |
Hopper capacity | Feed port size |
Maximum discharge port Opening setting |
||
| HX1315 |
1, widely used in primary crushing in various crushing processes 2, Crushing of various types of mining rocks 3, solid waste resource utilization, such as house demolition and recycling and crushing of road concrete; 4, material crushing in other industries. |
150-220t/hActual output Depends on raw material composition, feed size, pre-screening |
9m³ | 860mmx1520mm | 350mm | ||
|
Minimum discharge port Opening setting |
External power supply | engine | weight | Shipping size wxya | price | Options | |
| 350mm | 287KW (Without engine power) | 130KW | 43000kg | 18mx3.3mx3.8m | 200Ten thousand | Screen feeder,Waste belt | |
